model ZKLF40115-2Z3)

quality m

≈kg	2.200

size mm

d	40.000
D	115.000
B0-0.25	46
d1	65
r min	0.6
r1 min	0.6
J	94
d2	8.800
b	3
I	36

installation size mm

Da max	80
da min	56

set bolt

DIN912-10.9 specifications	M8
quantity	12

angle t

quantity ×t	12×30°

Basic rated load axial

live load Ca N	72000
dead load Coa N	149000

limit speed

nGfat min-1	3100

Bearings friction torque

MRL Nm	0.65

Stiffness axial

CaL N/μm	1200

Overturning stiffness

cKL Nm/mrad	750

mass mement of inertia

Mm kg·cm2	5.5

Axial runout

μm	2.5

Recommended INA locking nuts must be ordered separately

Model 1	ZMA40/62
Model 2	AM40
Locking torque MA Nm	110
Axial preload N	25815
